Basic parameter |
Description |
|
Main control scheme |
Mstar 8328P chip |
|
Lens wide angle |
140 °wide angle |
|
Photosensitive element |
CMOS HD Sensor Ov4689 |
|
Display screen |
TFT-LCD2.0 inch high resolution liquid crystal display |
|
Voice broadcast |
There is a voice prompt when the alarm number is recorded and broadcast |
|
Digital zoom |
128 times digital zoom |
|
Memory capacity |
Maximum support for 128GB |
|
Fast playback |
Playback of video, audio and picture files, video playback can be 2 to 128 times fast forward and fast back browse |
|
Vehicle mode |
Turn on the car mode, power on and record |
|
Virus firewall |
Disk write protection, files can be exported, not imported, to prevent virus intrusion |
|
Close beat mode |
After the close beat mode is turned on, the acousto-optic screen of the machine is completely shielded |
|
Vibration video |
Turn on the vibration video, and the equipment senses the vibration of the fuselage and starts recording |
|
Motion detection |
Turn on the motion detection mode, and the device detects the moving picture and starts recording |
|
Remote control |
Support for external HD cameras, dual HD video |
|
External equipment |
Support for 2.4G wireless remote control one-click video / recording / photography / shutdown |
|
Video resolution |
2304x1296/30p 1920x1080/30p 1280x720/30p 1280x720/60p 848x480/30p |
|
One-click video |
When the machine is off, long press the video key to turn on the device and start the camera |
|
Video format |
MOV |
|
Watermark display |
Device ID, police officer ID, date and time |
|
Video pre-recording |
The pre-recording time is 15 seconds before the video is started |
|
Delayed video recording |
5 seconds / 15 seconds / 30 seconds |
|
Audio frequency |
High quality built-in microphone |
|
One-click recording |
When the machine is turned off, the long press of the recording key will turn on the system and start recording |
|
Recording format |
WAV |
|
Photo resolution |
40M 38M 34M 14M 12M 8M |
|
Photo format |
JPEG |
|
Multiple continuous shots |
Number of consecutive photos supported: 5-10-20 |
|
Capture |
Support for capture photos in video shooting |
|
Exposure compensation |
Adjustment: 0.0EV ~ ±2.0EV |
|
Laser positioning lamp |
Surveillance video interface enabled to assist video positioning |
|
White light lamp |
Surveillance video interface enabled, night lighting |
|
Infrared night vision lamp |
Surveillance video interface is manually enabled for night / dark scene work |
|
Night vision distance |
5 meters to see the characteristics of the characters, 10 meters to see the outline of the characters |
|
Work indicator |
The LED is green when standby, yellow when recording, green when taking pictures, red when recording, green when charging, and red when off |
|
Size |
79x58x31 (mm) |
|
Quality |
130g |
|
Anti-fall height |
3 m |
|
Waterproof grade |
IP65 |
|
Battery capacity |
2850mAh lithium battery |
|
Standby time |
Continuous standby for more than 16 hours |
|
Charging time |
Fast charging function, battery charging time 4 hours |
|
time |
On / off, automatic correction time after positioning, host computer can also correct synchronization |
|
Screen saver |
Settings: 30 seconds / 1 minute / 3 minutes / 5 minutes / off |
|
Automatic shutdown |
30 seconds / 1 minute / 3 minutes / 5 minutes / off |
|
USB interface |
USB 2.0 |
|
Automatic screen closing |
Settings: 30 seconds / 1 minute / 3 minutes / 5 minutes / off |
|
Volume control |
Settings: high / medium / low |
|
Cue tone |
On / off |
|
Video and sound |
Video sound can be turned off and silent video can be recorded |
|
Video segmentation |
Can set 5, 10, 15, 30, minute video automatic segmentation, there is no interval between the two videos |
|
Password protection |
On / off |
|
Modify equipment number |
On / off |
|
File view mode |
Photo mode / file mode |
|
Default settin |
Restore factory settings |
|
Remote control |
Open / close |
|
Equipment information |
Software version |
|
Standard fittings |
Mainframe, back clip, shoulder clip, data cable, charger, specification, warranty card, certificate, packing box |
